ANIMation MOD Tool

Updated

2024-07-20

Premium

Code Plugins

Engine version

5.3 , 5.4

Download type

Engine Plugin

File size

16.4 MB

Only For Premium or VIP Users

Description

Animation Blend, time manipulate, loop, mirror, reverse and more in seconds.

Anim Mod Tool ( works with any skeleton )

Attention:5.4 version update didn't went so well. You might experience UE5 crashing, when trying to open animation editor. We are working on solving this issue with Epic's team. Thank you.

is a Fast and easy approach to Reverse your animation, Mirror animation, Blend animation, Loop animation, manipulate time, pick hand poses, adjust and mix your animation assets. Great solution to create new assets, or change your existing mocap and hand crafted animations.

Features:

Reverse Animation ( + offset root to world 0 )
Mirror Animation
Loop Animation (update 1.1)
Blend With Other (added static pose blend in Update 1.3)
Time Manipulation (added in Update1.3)
Hand Poses blend (added 60 hand poses in Update 1.3)
Repeat frames (update 1.1)
Remove frames (update 1.1)
Live updating viewport (update 1.2)

UPDATE 1.3

"Use static frame" in Blend ( let's you pick any frame from target animation and blend it to the source)
Time Manipulation (let's you speed up or slow down certain parts of your animation)
Hand Poses blend (let's you quickly blend hand poses to your animation. 60 male & female hand pose library included)

UPDATE 1.2

Bone chain selector for Blend
Live viewport ( Now you can see live update on the changes you make before applying)

MAJOR UPDATE 1.1

video tutorial and price adjustments for the new features are coming soon ;)

Added:

Clear Root bone zero frame offset in Reverse animation - let's you offset the root to 0 at the start of the animation
Repeat frames - this modifier lets you repeat any frame to add pause or exaggerate certain parts of the animation .
Make Looped - let's you blend the beginning and the end of the animation to make them loop (includes an option to add extra frames to the end of the animation if needed and pick the parent bone from which changes should be applied)
Remove frames - let's you remove unnecessary frames of the animation
Blend with other - let's you build completely new animation asset by blending with another animation. Options include:

The quick guide on how to apply blend:

"Start frame" picking the start frame from which the blending starts in the source of the animation. (example: if you want blending to start at the beginning, then select 0 )

"Target asset" picking target animation

"Target start frame & target frames num" picking target's animation's duration in the blend (how many frames of the animation should be blended with the source animation) (example: slide to max. for full duration)

"Start blend frames num" is picking amount of frames to blend in between two animations, for smooth transition between poses at the beginning of the blend + pick blend curve (in case you want blend to start at the certain frame)

"End blend frames num" picking amount of frames to blend out at the end + blend curve (in case source animation is longer)

"Bone Filter" let's you pick the parent bone from which the blending should start (for example to blend top and bottom motion of the two animations, for example UE character, you should pick spine01 or higher. Then you will have bottom motion of your source animation blended with the top motion of your target animation)

'insert as new frames" means that you can insert target animation between frames of the source animation without change.

for now plugins works best for blending animations with the same frame rate

______________________________________________________________________________________________________

Practical usage:

Right Mouse Button will open context menu
Click on Modify Animation Sequences
Tool popup will appear
Configure modify options
Click on Apply button (duplicate your animations before using the plugin. There is no going back after applying the changes)
Close popup to check updated Animation Sequences
Note: only reverse and mirror can be applied to multiple assets at the same time

ATTENTION: RM Fix Tool might be useful to fix any root motion issues of the animations, create or remove it. Also change direction of the animation and to snap IK bones.

Technical Details

Features:

Create reversed Animation Sequences from original ones
Create mirrored Animation Sequecnes from original ones

Added in Update 1.1:

Clear Root bone zero frame offset in Reverse animation ( let's you offset the root to 0 at the start of the animation)
Repeat frames
Make Looped
Remove frames
Blend with other

Added in Update 1.2
